Zimo ADAMTC 21pin Booster Board

44 x 26.5 x 6mm

NOTE: The ADAMTC is no longer in production - use PluX22/ADAPLU as an alternative

Description

Zimo's ADAMTC booster board takes a 'C' type 21pin decoder and boosts the motor output to support a continuous running of 1.8A instead of the usual 1.2A continuous. Peak of 2.5A remains the same for short periods.

In addition, the ADAMTC also converts the FA3/FA4 logic level outputs of the 'C' type to full power outputs.

Note that the ADAMTC is designed really for the MX644C and MX634C decoders. MS440C will also work, but you must not attempt to connect lighting outputs from FA5 or above, as the characteristics are different and pin layout will also not match. If you wish to boost the motor on an MS sound decoder then we suggest you use the MS450PluX22 with an ADAPLU booster instead.

×
