Zimo MN300 ('R' 8pin on harness, 'F' 6pin on harness, 'P16' PluX16 direct plug-in) Standard Decoder

Code: MN300

× Cancel

Zimo MN300 Standard Decoder

18x10.5x3.1mm 1A continuous / 1.5A peak 16V/15000uF direct, or more via LifeLink/SACC16/STACO 'R' 8pin on harness, 'F' 6pin on harness, PluX16 direct plug-in 6 full power outputs

Variants / Sub-Products

MN300R	× Cancel	'R' Version 8pin on harness
MN300F	× Cancel	'F' Version 6pin on harness
MN300P16	× Cancel	'P16' Version PluX16 direct plug-in

Description

The MN300 standard decoder from Zimo uses the same technology platform as Zimo MS sound decoders, just without the audio facilities.

Technical Specification

• 1A continuous motor output / 1.5A peak for short periods
• 6 full power function outputs, max combined 0.8A
• 2 logic level outputs e.g. servo control / SUSI
• Direct connection of 16V up to max 15000uF, or more via LifeLink/SACC16/STACO
• Railcom
• DCC, DC-Analog, MM, AC-Analog, Mfx

×
